MODEL   NAME : L135-L567L000KL030

Manufacturer  :

Forward Current      (IF ):  200mA

Pulse Forward  Curren t1(IFp): 240mA

Reverse  Current    (IR): mA

Reverse Voltage(VR):   V

Power Dissipation  (PD): mW

Operatin  Tgemperature(Topr):-40   +105°C

Storage Temperature   (Tstg):  -40  -  +105°C

Soldering Temperature     (Tsld):  Reflow Soldering:260°C

for 10secs

Hand Soldering:350°C

for 3secs

Junctio  Tnemperature(Tj):  125°C

Forward  Voltage(VF):   2.8-3.5V  (100mA)

Luminous Flux    (LM):     44-56LM    (100mA)

Wavelength    (nm):  nm  (100mA)

CIE : x=0.3773   y=0.5076  (100mA)

CRI  :   °

Viewing angle : 120 °

Lead Frame Type LED Package:
